KS系列产品技术参数
| 产品型号 | 排气压力(Mpa) | 排气量(m3/min) | 电机功率(KW) | 排气接口 | 重量(KG) | 外形尺寸(MM) |
| KS30 | 0.8 | 0.25 | 2.2 | 3/8″ | 150 | 1070×400×820 |
| KS40 | 0.8 | 0.4 | 3 | 3/4″ | 230 | 1400×510×1120 |
| KS55 | 0.8 | 0.55 | 4 | 3/4″ | 280 | 1400×510×1120 |
| KS75 | 0.8 | 0.7 | 5.5 | 3/4″ | 305 | 1500×550×1180 |
| KS100 | 0.8 | 1 | 7.5 | 3/4″ | 340 | 1500×550×1180 |
| KS100X | 0.8 | 1 | 7.5 | 3/4″ | 355 | 1500×550×1180 |
| KS100C | 0.8 | 1 | 12.13 | 3/4″ | 400 | 1750×600×1300 |
| KS150 | 0.8 | 1.4 | 11 | 3/4″ | 465 | 1690×630×1300 |
| KS200 | 0.8 | 1.9 | 15 | 3/4″ | 580 | 1700×660×1340 |
| KS240 | 0.8 | 2.1 | 15 | 3/4″ | 650 | 1750×690×1400 |
| KSH100 | 1.25 | 0.8 | 7.5 | 3/4″ | 350 | 1500×550×1180 |
| KSH100D | 1 | 1.05 | 7.5 | 3/4″ | 350 | 1500×550×1180 |
| KSH100C | 1.25 | 0.8 | 12.13 | 3/4″ | 400 | 1750×600×1300 |
| KSH150 | 1.25 | 1.2 | 11 | 3/4″ | 480 | 1690×630×1300 |
| KSH150D | 1 | 1.6 | 11 | 3/4″ | 480 | 1690×630×1300 |
| KSH200 | 1.25 | 1.7 | 15 | 3/4″ | 600 | 1700×660×1340 |
